At a glance data:
Gas Standby Rating:
3120 ekW @ 1.0pf
Fuel Type:
Natural Gas, Hydrogen Blend (up to 5%)
Emissions/Fuel Strategy:
U.S. EPA Stationary Non-Emergency Certified
RPM:
1800 rpm
Overview
Category:
Gas Generator Sets
Category:
Gas Generator Sets
Brand:
Caterpillar
Brand:
Caterpillar
Generator Set Specifications
Gas Standby Rating:
3120 ekW @ 1.0pf
Fuel Type:
Natural Gas, Hydrogen Blend (up to 5%)
Emissions/Fuel Strategy:
U.S. EPA Stationary Non-Emergency Certified
RPM:
1800 rpm
Frequency:
50 / 60 Hz
Maximum Electrical Efficiency:
39.6%
Engine Specifications
Engine Model:
G3520
Displacement:
5956in³
Aspiration:
TA
Bore:
6.7in
Stroke:
8.5in
Generator Set Specifications
Compression Ratio:
10.2
Generator Set Dimensions
Length:
260in
Width:
86in
Height:
99in
Weight:
48444lb
Generator Set Specifications
Frequency:
50/60 Hz
Engine Specifications
Compression Ratio:
10.2:1
Generator Set Specifications
Speed:
1800 RPM
Standard Equipment
air inlet
- Single element air cleaner with package and service indicator
control panel
- Cat ECS 100
cooling
- Jacket water and SCAC engine-driven pumps
- Jacket water and SCAC thermostats
exhaust
- Dry exhaust manifolds, insulated and shielded
- Cat-flanged face outlet on turbocharger
fuel system
- 24V DC energized-to-run (ETR) gas shutoff valve
- Gas pressure regulator
- Engine-installed electronic control valve
- Fuel system is sized for 31.5 to 47.2 MJ/NM3 dry pipeline natural gas with pressure of 10.2 to 34.5KPa to the engine fuel control valve
general
- Paint- Caterpillar Yellow with high gloss black rails and radiator
- Parts book
- Operation and maintenance manuals
- Crankshaft vibration damper and guard
- RH Service
generator
- SR5 / N9500
- Winding temperature detectors
- Permanent Magnet Excitiation
- Integrated voltage regulator (IVR)
- Anti-condensation space heater
- NEMA Class H insulation
- Cat Gearbox (50 Hz)
starting/charging
- Electric Starter
- Jacket water heater
- 24V starting motors
- Battery with cables and rack (shipped loose)
governing system
- ADEM 6
ignition system
- Integrated Cylinder Pressure Sensor (ICPS)
- Electronic Ignition System (controlled by ADEM)
Optional Equipment
air inlet
- Air cleaner with precleaner
control panel
- Engine failure relay
- Remote PC monitoring
- DIO Modules
- Load Share Module
- Cat ECS 200
- CAN Wiring
circuit breakers
- 100% rated, 3-pole (UL/CSA/IEC) 5th Digit Rating
- 2000A, 2500A, 3000A 3 Pole, UL-100% Rated Masterpact Circuit Breakers
- 3-pole (IEC 947-2 rated)
- 1600A, 2000A 3 Pole, UL-100% Rated R-Frame Circuit Breakers
- Frame mounting
- S LSI, G LSIG, P LSIG-P, 4th Digit Type
cooling
- Factory provided remote radiator
exhaust
- 305 mm (12 in.) flange
- 305 mm (12in.) elbow
- 305mm (12 in) spark arresting muffler
- 305 mm (12 in.) muffler
- 18, 25 dBA Attenuation
fuel system
- 3, 0-100 kPag, 4-20mA gas train pressure sensors
general
- Digital diagnostic tool
generator
- European bus bars
- Low voltage extension box
- Generator air filter
- Cable access box
- Bearing temperature detectors
starting/charging
- 20/35/50A, 24VDC battery charger
- 50A, 24V charging alternator (requires engine driven pumps)
