At a glance data:
Rating Prime:
60 kVA
Frequency:
50/60 Hz
Voltage:
220 - 480 V
Engine:
Cat C3.6
Overview
Category:
Mobile Generator Sets
Category:
Mobile Generator Sets
Brand:
Caterpillar
Brand:
Caterpillar
Generator Set
Rating Prime:
60 kVA
Frequency:
50/60 Hz
Voltage:
220 - 480 V
Engine
Engine:
Cat C3.6
Fuel:
Diesel
Dimensions
Width:
45.0in
Height:
69.9in
Length:
104.2in
Weight - With Lube Oil and Coolant:
3918lb
Fuel Consumption EU Stage V
100% Load 50Hz:
3.77gal/hr
100% Load 60Hz:
3.46gal/hr
75% Load 50Hz:
2.76gal/hr
75% Load 60Hz:
2.74gal/hr
50% Load 50Hz:
1.94gal/hr
50% Load 60Hz:
1.98gal/hr
Noise rating (with enclosure) EU Stage V
Sound Power @ 1 meters (3 feet) @ 75% of rating (50Hz):
93 dB(A)
Sound Power @ 1 meters (3 feet) @ 75% of rating (60Hz):
97 dB(A)
Standard Equipment
cat c3.6 diesel engine
- Turbocharged
generator
- M1775L4 Frame
air filter
- Cartridge-type air filter with service indicator
cat connect remote monitoring
- Provides package monitoring and management
cooling system
- Package mounted radiator with vertical air discharge. Filled from factory
charging / starting system
- 12V heavy duty starting motor and charging alternator c/w battery isolator
fuel system
- 24 hour dual wall fuel tank with 3 way directional valve for external supply
control panel
- Digital XQCP set mounted controller
distribution
- Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off
structure
- Heavy Duty steel base frame with integral fuel tank. Fork lift pockets. Dragging bars. Lifting frame and 4 point lift. base frame is wider than enclosure to protect generator set during transportation.
enclosure
- Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance
exhaust
- Integrated spark arresting silencer
lube oil
- On engine primary and secondary oil filters. Filled from factory
general
- Factory tested and inspected
