At a glance data:
Drive Shaft Torque at Maximum Pressure:
1699.3lb/ft
Drive Method:
Gerotor Motor - Direct Drive
Mounting Bracket Design:
Skid Steer Loader Coupler
Required Hydraulics:
Standard Flow
Overview
Cat® Augers are used for drilling holes for footings, fencing, signs, trees and shrubs in construction, agricultural, and landscaping applications. They are designed with the right amount of speed and torque for maximum productivity in a broad range of soil types.
Category:
Augers
Category:
Augers
Brand:
Cat
Brand:
Cat
Drive Shaft Torque at Maximum Pressure: 1699.3lb/ft
Drive Shaft Torque at Maximum Pressure:
1699.3lb/ft
Drive Method: Gerotor Motor - Direct Drive
Drive Method:
Gerotor Motor - Direct Drive
Mounting Bracket Design: Skid Steer Loader Coupler
Mounting Bracket Design:
Skid Steer Loader Coupler
Required Hydraulics: Standard Flow
Required Hydraulics:
Standard Flow
Optimal Hydraulic Flow: 42-83 L/min (11-22 gpm)
Optimal Hydraulic Flow:
42-83 L/min (11-22 gpm)
Optimal Hydraulic Pressure: 145-235 bar (2100-3400 psi)
Optimal Hydraulic Pressure:
145-235 bar (2100-3400 psi)
Overall Width - With Bracket: 45in
Overall Width - With Bracket:
45in
Overall Length - With Bracket: 23.5in
Overall Length - With Bracket:
23.5in
Overall Height: 40.2in
Overall Height:
40.2in
Housing Diameter: 9.9in
Housing Diameter:
9.9in
Swing Range: 102 degrees
Swing Range:
102 degrees
Swing Range (fore/aft): 120 degrees
Swing Range (fore/aft):
120 degrees
Swing Range (L/R): 102 degrees
Swing Range (L/R):
102 degrees
Weight: 423.3lb
Weight:
423.3lb
Motor Displacement: 38in³
Motor Displacement:
38in³
Bit Speed at Maximum Flow: 127 rpm
Bit Speed at Maximum Flow:
127 rpm
Hex Output Shaft Size: 2in
Hex Output Shaft Size:
2in
Standard Equipment
Optional Equipment
