Peterson BTS50 Stand-Alone Blower Unit

At a glance data:

Engine:
Caterpillar C7.1 Tier IV 225 hp/Caterpillar C9.3B Tier IV 335 hp
Fuel Tank Capacity:
115 gal
Machine Weight:
Box Only: 16,700 lbs, with Typical Options approx: 34,160 lbs
Print

Overview

With a Peterson BTS50 Stand-Alone Blower Unit, you can tackle an even wider range of projects, gain productivity, and boost your profitability. The BTS50 is available in two models, the standard BTS50 is powered by a CAT C7.1 Tier IV engine with 225 hp (167 kW), or the BTS50+, with a CAT 9.3B Tier IV engine with 335 hp (250 kW) for heavy-duty applications such as delivering light aggregate materials. With the stand-alone power plant, the BTS50 allows you to blow material while moving the truck, which is ideal for jobs that require lots of repositioning. The BTS50’s blower unit is rated at 15 psi (1.03 bar) for typical applications of mulch or compost materials. The BTS50+ has a 20 psi (1.38 bar) blower unit, and is specifically designed for tough-to-blow applications.

Category:
Blower Trucks & Trailers

Brand:

General Specifications

Engine:
Caterpillar C7.1 Tier IV 225 hp/Caterpillar C9.3B Tier IV 335 hp
Fuel Tank Capacity:
115 gal
Machine Weight:
Box Only: 16,700 lbs, with Typical Options approx: 34,160 lbs

Standard Equipment

dimensions

  • Operating Length: 40' 2"
  • Operating Width: 8' 6"
  • Operating Height: 13' 4"
  • Loading Height: 12' 9"
  • Stand Alone Unit Length: 30' 11"
  • Frame Length: 26' 9"
  • Box Length: 21' 10"
  • Box Width: 8' 1"
  • Box Height: 8' 5"
  • Box Volume, Struck: 48 yds³
  • Box Volume, Typical: 45 yds³
  • Axle Spacing: 54"
  • Tool Box: 60"

weights

  • Weight with Typical Options: 47,500 lbs / 48,700 lbs
  • Box Only Weight: 27,500 lbs / 28,700 lbs

truck platform

  • Chassis: any Class 8
  • Standard Chassis: Peterbilt 567
  • Cab Configuration: Driver Bucket Seat & 2-Person Bench Seat

powertrain

  • Engine: Caterpillar C7.1 Tier IV 225 hp / Caterpillar C9.3B Tier IV 335 hp
  • Fuel Tank Capacity: 115 gal
  • Hydraulic Tank Capacity: 83 gal
  • DEF Tank Capacity: 17 gal

system controls

  • Peterson Adaptive Feed System: Yes
  • Radio Remote: Yes

feed & blower systems

  • Floor: Aluminum Walking Floor / Stainless Steel Walking Floor
  • Wear Liners: Aluminum / Hardox 450 Steel
  • Blower: Tri-Lobe® / Tri-Lobe®
  • Blowing Pressure: 15 psi / 20 psi
  • Large Capacity Silencer: Intake and Discharge / Intake and Discharge

discharge system

  • Hose Reel: powered, holds up to 320 ft
  • Discharge Hose Length: 20 ft heavy-duty, 300 ft standard
  • Hose Diameter: 5", 4"

production

  • Discharge Volume: up to 60 yds³
  • Material Weight: up to 2,100 lbs/yd³ / up to 2,700 lbs/yd³
