Weiler S340 Wheel Skidder

At a glance data:

Engine Model::
Cat® C7.1 Stage 5
GROSS POWER::
265 hp (198 kW)
ENGINE SPEED::
2200 rpm
FUEL CAPACITY::
100 gal (378 L)

Overview

The Weiler S340 Wheel Skidder is built for high productivity, operator comfort, and long-term durability with a simplified, continuously variable-speed hydrostatic ground drive that delivers smooth operation, strong pulling power, and optimal ground speed for efficient skidding. Its high-capacity, multi-function hydraulics allow operators to steer and control other functions simultaneously, while independent front and rear differential locks provide excellent traction and performance in tough, wet logging conditions. A spacious, comfortable cab features large front and rear glass, a narrow sloped hood for exceptional visibility, and ergonomic joystick steering with customizable button mapping and optional mechanical rotating seat controls. Operator access is made easy with wide steps, 90-degree door openings, and conveniently placed ground-level service points, including the DEF tank, cab tilt pump, hydraulic fill pump, and battery access in side-mounted saddle bags. The machine’s clean, robust design features 50% fewer hoses in the center section, a front-mounted variable-speed reversing fan, and durable construction components like dual tapered roller bearing hitch pins and thick steel panels—resulting in lower operating costs, easier serviceability, and maximum structural life in demanding forestry environments.

Category:
Wheel Skidders

Brand:

General Specifications

Engine Model::
Cat® C7.1 Stage 5
GROSS POWER::
265 hp (198 kW)
ENGINE SPEED::
2200 rpm
FUEL CAPACITY::
100 gal (378 L)
DEF CAPACITY::
5.0 gal (19 L)
WHEELBASE::
160" (4064 mm)
WEIGHT::
45,620 lb (20 693 kg)
TRANSPORT WIDTH::
11’ 7” (3.53 m)
TRANSPORT HEIGHT::
11’ 4” (3.45 m)
TRANSPORT LENGTH::
28’ 0” (8.53 m)
GROUND CLEARANCE::
26.0” (660 mm)
BOX GRAPPLE TONG CAPACITY::
17 ft² (1.6 m²)
BOX GRAPPLE TONG OPENING::
127" (3226 mm)
BLADE GRAPPLE TONG CAPACITY::
18 ft² (1.67 m²)
BLADE GRAPPLE TONG OPENING::
145.0" (3683 mm)

Standard Equipment

powertrain

  • Cat C7.1 dual turbo engine certified to EPA Stage 5
  • Primary and secondary fuel filters, including water separator
  • Electric fuel priming and transfer pump
  • Integrated engine pre-cleaner with 2-stage filter
  • Front mounted cooling package
  • Variable-speed, hydraulic driven reversing fan
  • Variable-speed hydrostatic ground drive
  • HD axles, approved for dual tires up to 35.5L-32 with 24.5L-32 outer tires and single wide tires up to 73x44 with chains
  • Independent front and rear differential locks
  • Lubed for life universal joints and HD drive shafts
  • Enclosed disc service brakes on front axle
  • Enclosed parking brake - spring applied, hydraulically released

operator environment

  • Wide, enclosed cab
  • Joystick steering with front foot controls
  • High-capacity HVAC system
  • Air suspension seat with 4-point harness seat belt
  • AM/FM/Bluetooth Radio
  • 24V to 12V converter, 12V power port, and 2x USB ports
  • 4 LED cab lights
  • Weiler machine software

hydraulics

  • Load-sense hydraulics
  • Variable displacement pumps
  • High performance, multi-functioning main control valve
  • Spin-on filters

electrical

  • 115 ampere alternator
  • 24-volt electrical system with 2x 12-volt batteries
  • Main disconnect switch with Diesel Exhaust Fluid (DEF) purge indicator light
  • Product Link™ Ready

sales and service

  • Sold and serviced exclusively through Weiler Forestry dealers worldwide.

other standard equipment

  • Heavy-duty frames
  • Narrow engine enclosure with high front visibility
  • Single side engine service
  • Dual tapered roller bearing upper and lower center hitch
  • Heavy-duty limb risers
  • Wide water tank ready decking blade with welded on cutting edge
  • Tilt cab
  • Electric hydraulic oil fill pump

optional equipment

  • Dual Function Arch/Boom and Grapple Head
  • Cable Arch w/ High Speed Winch and Extreme Duty Fenders
  • 17 ft² & 19 ft² HD Box Tong or 18 ft² Blade Tong Grapples
  • No Winch, Winch Ready, Standard Winch, or High-Speed Winch
  • Grapple Fenders
  • Weighted Decking Blade
  • Standard or Weighted Decking Blade w/ Bolt-on Cutting Edges
  • Front Axle w/ Limited Slip Differential
  • Wheel Steering
  • High Rotation Joystick Seat w/ Added Rear Foot Controls
  • High Intensity Cab Mounted Light Bars
  • High Intensity Cab Mounted Light Bars w/ Additional 3 Boom Lights
  • Pressurized Blade Mounted Water Tank
  • CB Radio
  • Engine Driven Cooling Fan
  • Product Link™ (PL243 Cellular or PL631 Satellite)
  • Ether Starting Aid
  • 7/8” x 75’ Winch Cable w/ 7 Ton Hook
  • 5 LB Fire Extinguisher
  • Water Tank Fill w/ RV Antifreeze
  • 30.5L-32 NOAW Tires - 126.6" (3220 mm)
  • 30.5L-32 Tires - 133.3" (3390 mm), Approved for Chains
  • 30.5L-32 2x Ring Tires - 126.6" (3220 mm)
  • 35.5L-32 NOAW Tires - 139.1" (3530 mm)
  • 35.5L-32 2x Ring Tires - 139.1" (3530 mm)
  • 35.5L-32 Tires - 145.8" (3700 mm), Approved for Chains
  • 73x44-32 Tires - 158" (4000 mm)
  • 30.5 or 35.5 Tubes (Set of 4)

warranty

  • 12 months standard. Extended warranty available.
