RM400 Road Reclaimer

At a glance data:

Maximum Operating Weight:
57682lb
Cutting/Mixing Width:
96in
Maximum Cutting/Mixing Depth:
20in
Operating Speed:
2.97mile/h
RM400 Road Reclaimer

Overview

The versatile Cat® RM400 Reclaimer/Stabilizer delivers excellent material gradation, outstanding maneuverability, and simple operation with superb visibility for excellent overall job site performance. Your toughest road rehabilitation and soil stabilization jobs have met their match.

Category:
Road Reclaimer

Brand:
Caterpillar

Weights

Maximum Operating Weight:
57682lb

Operating Specifications

Cutting/Mixing Width:
96in
Maximum Cutting/Mixing Depth:
20in
Operating Speed:
2.97mile/h
Maximum Travel Speed:
6.8mile/h
Rotor Options:
Universal, Combination, Spade
Rotor Speed - First (at 2100 Engine rpm):
108r/min
Rotor Speed - Second (at 2100 Engine rpm):
134r/min
Rotor Speed - Third (at 2100 Engine rpm):
159r/min

Engine

Gross Power:
415.7hp
Engine Model:
Cat C9.3B

Dimensions

Length:
31.4ft
Width:
9.8ft
Maximum Height:
11.5ft
Wheel Base:
20.7ft
Ground Clearance:
19.7in

Service Refill Capacities

Fuel Tank Capacity:
279gal (US)

Standard Equipment

operating environment

  • Adjustable armrests
  • Air-ride, heated suspension seat
  • Audio-ready with speakers
  • Full width sliding cab with heat and air conditioning
  • Push button start
  • Illuminated dual-side access ladders
  • High visibility retractable seat belt
  • Mini-wheel steering control
  • Multifunction propel lever
  • Steering guides
  • Color touch screen operator interface

powertrain

  • Air to Air Aftercooler (ATAAC)
  • Dual element air cleaner with pre-cleaner
  • Extended life coolant with protection to -37 degrees C (-35 degrees F)
  • On-demand fan with auto-reversing function
  • Four steering modes
  • All-Wheel Drive
  • Electronic differential
  • Oil-bath brake system
  • Powertrain guard

electrical system

  • 150 amp alternator
  • 24-volt charging system
  • Automotive-type fuse system
  • Remote start/charge receptacle
  • Two 1365 CCA maintenance-free batteries

rotor drive system

  • Maintenance-free drive shafts
  • Self-lubricating roller and bearings
  • Shear disk driveline protection
  • Automatic depth control
  • Hydraulically-controlled dry clutch
  • Three rotor speeds
  • Variable volume mixing chamber

service and maintenance

  • Grouped filters with ground level access
  • Cat Product Link™
  • Remote Flash
  • Remote access drains
  • Ports for Scheduled Oil Sampling (S·O·S)
  • Fluid level sight gauges
  • Service light receptacles
  • Toolbox

safety

  • Back-up alarm (front and rear)
  • Front and rear facing cameras
  • Ground level emergency shutdown switches (3)
  • Horn (front and rear)
  • ROPS
  • Platform handrails and guardrails
  • Mirrors
  • Working lights (halogen or LED)

Optional Equipment

operating environment

  • Additional color touch screen

powertrain

  • Bio-friendly hydraulic oil

spray systems

  • Water spray system
  • Emulsion spray system
  • Push bar

rotor drive system

  • Torque limiter driveline protection
  • Rotor - Universal
  • Rotor - Combination
  • Rotor - Spade
  • Material sizing breaker bar

service and maintenance

  • Integrated air compressor
  • Pneumatic bit removal tool
  • Additional toolbox

safety

  • LED roading lights
  • Folding LED safety beacon
  • Folding side view cameras (2)
  • Front and rear rotor chamber door cameras
