At a glance data:
Maximum Rating:
800 ekW
Minimum Rating:
635 ekW
Emissions/Fuel Strategy:
Low Fuel Consumption
Voltage:
220 to 480 Volts
Overview
Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.
Category:
Diesel Generator Sets
Category:
Diesel Generator Sets
Brand:
Cat
Brand:
Cat
Generator Set Specifications
Maximum Rating:
800 ekW
Minimum Rating:
635 ekW
Emissions/Fuel Strategy:
Low Fuel Consumption
Voltage:
220 to 480 Volts
Frequency:
60 Hz
Speed:
1800 rpm
Duty Cycle:
Standby, Prime
Engine Specifications
Engine Model:
3412C TA, V-12, 4-Stroke Water-Cooled Diesel
Bore:
5.4in
Stroke:
6in
Displacement:
1648.86in³
Compression Ratio:
13:00:01
Aspiration:
TA
Fuel System:
Pump and Lines
Governor Type:
ADEM™ A5
Generator Set Dimensions
Length - Maximum:
162.4in
Width - Maximum:
78.3in
Height - Maximum:
75in
Dry Weight - Genset (minimum):
5761lb
Dry Weight - Genset (maximum):
13275lb
Standard Equipment
air inlet system
- Air cleaner, single element canister type
- Single element canister type
control panel
- Failure to start (overcrank)
- Emergency stop
- EMCP 4.2B
- Speed adjust
- Remote Serial annunciator
- Communications:
- Controls:
- Digital Indicator for:
- Engine cycle crank
- Voltage adjust
- Compatible with the following optional modules:
- Digital I/O module
- Overspeed
- Low coolant level
- Serial annunciator module data link
- Volts (L-L & L-N)
- Emergency stop pushbutton
- Generator temperature monitoring module
- Frequency (Hz)
- Run/auto/ stop/control
- DC volts
- High coolant temperature
- Oil pressure (psi, kPa or bar)
- Customer data link (Modbus RTU)
- RPM
- coolant temperature
- Amps (per phase & average)
- Operating hours.
- Local annunciator
- Low oil pressure
- Power factor (per phase & average)
- Remote CAN annunciator
- Low coolant temperature
- Accessory module data link
- Warning shutdowns:
cooling system
- Coolant drain line with valve
- Caterpillar extended life coolant
- Fan and belt guards
- Radiator with guard (sized for 50 degrees C)
exhaust system
- Stainless steel exhaust flex with ANSI style outlet flange
fuel system
- Primary and Secondary fuel filters
- Water separator
- Fuel priming pump
generator and attachments
- 3 Phase sensing
- Class H insulation
- Busbar termination
- 12 Leads
- SR4B self excited
- Reactive droop
- Class F temperature rise
- VR6B voltage regulator
- 2:1 Volts/Hz
governing system
- Cat electronic governor
lube system
- Oil drain line with valve
- Oil filter
- Lubricating oil
mounting system
- Base, formed steel with linear vibration isolators between base and engine-generator
starting / charging system
- 45 Amp Charging alternator
- Fuel shutoff solenoid
- 24 Volt starting motor
- Battery with rack, cables
general
- Paint - Caterpillar yellow except rails and radiators gloss black
Optional Equipment
air inlet system
- Air cleaner - single element
- Air cleaner - Dual element
- Air cleaner - Heavy element
certificates
- EU Certification
circuit breakers
- 3 Pole Circuit breakers with shunt trip
- Power terminal strip
- 4 Pole Circuit breakerswith shunt trip
control panel
- Temperature monitoring package
- EMCP 4.3, EMCP 4.4
- Vandal proof panel door
- Common alarm/shutdown relay
- Generator running VFC
- Earth leakage Ground fault relay
cooling system
- Radiator removal
- Jacket water heater
- Radiator duct flange
exhaust system
- Through wall installation kit
- Manifold and turbocharger guards
- Muffler 35 dBA attenuation
- Muffler 10 dBA attenuation
- Elbow mounting kit
fuel system
- Automatic fuel transfer system
- Manual fuel transfer pump
generator and attachments
- Oversize and premium generators
- Permanent magnet excitation (PMG)
- Anti-condensation heater
- Internal excitation (IE)
governing system
- Electronic load share
lube system
- Manual sump pump
mounting system
- Fuel tank base (1200 Ltr)
special tests / reports
- PGS Test report @ 1.0 power factor
- Factory witness test
- PGS Test report @ 0.8 power factor
starting / charging system
- Battery chargers
- Oversize battery set
- Heavy duty starting system
- Battery disconnect switch
- Battery removal
enclosures
- DC lighting package
- Weather protective enclosure (WP)
- Sound attenuated enclosure (SA)
