At a glance data:
Engine:
Cat C9.3B Tier IV, 455 hp Cat C9.3B Tier III, 415 hp (export only)
Fuel Tank Capacity:
146 US gal
Machine Weight:
41,000 lbs
Overview
Heavy duty and mobile, the 1700D Horizontal Grinder can readily reduce a wide range of materials. The large feed opening on the 1700D measures 54″ x 27″ (137 x 69 cm). When boosted by the high-lift feed roll, the feed opening’s maximum lift of 41.5 inches (105 cm) can tackle the largest of feedstock, and allows excellent accessibility to the rotor for maintenance. The 1700D Horizontal Grinder is equipped with a Caterpillar Tier IV C9.3 455 hp (EU Stage V, 339 kW) engine, or an optional, export-only C9.3B Tier III, 415 hp (309 kW) engine. At 44,000 pounds (20 000 kg), it is the lightest of the grinder series, and is easily transportable.
Category:
Chippers and Grinders
Category:
Chippers and Grinders
Brand:
Brand:
General Specifications
Engine:
Cat C9.3B Tier IV, 455 hp Cat C9.3B Tier III, 415 hp (export only)
Fuel Tank Capacity:
146 US gal
Machine Weight:
41,000 lbs
Standard Equipment
dimensions
- Operating Length: 36' 3"
- Operating Width: 9' 6"
- Operating Height: 11'10"
- Travel Width: 8'4"
- Travel Length: 36'3"
- Travel Height: 11'10"
- Frame Length: 28' 6"
- Ground Clearance: 9"
- Axle Spacing: 51"
weights
- Machine Weight: 41,000 lbs
- 5th Wheel Weight: 9,000 lbs
- 5th Wheel Weight, EU Spec.: 2,200 lbs
- Tandem Axle Weight: 32,000 lbs
powertrain
- Engine: Cat C9.3B Tier IV, 455 hp; Cat C9.3B Tier III, 415 hp (export only)
- Clutch: PT Tech SCT 2500
- Fuel Tank Capacity: 146 US gal
- Main Hydraulic Tank Capacity: 72 US gal
- DEF Tank Capacity: 17 US gal
system controls
- Adaptive Control System: Yes
- Radio Remote: Yes
- Peterson+ Analytics: Yes
feed system
- Feed Opening (w x h): 54" x 27"
- Hopper Width: 54"
- Feed Conveyor Width: 4'6"
- Feed Chain: 4 sections, full hopper width
- Compression Roll Diameter: 24"
- Land Clearing Mode: 54" x 41.5"
rotor & grates
- Rotor Width: 55.5"
- Rotor Diameter: 26.5"
- Rotor Shaft Size: 4.33" @ bearing, 4.75" @ center
- Bit Size: 2.5" x 4.5"
- Number of Bits: 22 drum rotor, 18 pinned rotor
- Rotor Speed: 10,000 fpm @2200 rpm
- Number of Grate Sections: 3
- Total Grate Area: 15.6 ft²
- Grate Coverage: 174º
- Grate Thickness: 3/4"
discharge system
- Discharge Conveyor Width: Compact: 3' 6" / Short: 3' 6"
- Discharge Conveyor Height: Compact: 9' 2" / Short: 13' 6"
- Conveyor Speed: Compact: 500 or 600 fpm / Short: 500 or 600 fpm
production
- Greenwaste Volume: 140 yd³
- Greenwaste Weight: 39 tons
- Scrap Board Volume: 185 yd³
- Scrap Board Weight: 30 tons
options
- Magnetic Head Pulley: Yes
- LED Work Lights: Yes
- Dust Control: Yes
- Crossbelt Magnet: Yes
- Scrap Metal Collection Box: No
- Export Kit: Yes
- CE Certification: Yes
- Feed Tailgate: Yes
- Cold Weather Kit: No
- Air Compressor: No
- R+ Package: No
- ASG Package: No
- Flat Feed Deck: Yes
- Liquid Injection System: Yes
- Tow Dolly: No
- Short Discharge Conveyor: Yes
- Extra-Long Discharge Conveyor: Yes
