At a glance data:
Overview
Continuing Peterson’s long history of innovation, the 4800F Chain Flail Debarker is the 6th generation design and has all the features that clean chip operations demand. The Peterson 4800F Chain Flail Debarker multiple log delimber/debarker is designed to be used in tandem with whole tree chippers to produce high quality pulp chips. Capable of processing multiple logs from 2 to 23 inches (5–58 cm) in diameter, the 4800F increases productivity while reducing bark content, product handling time, and fiber loss. The 4800F Chain Flail Debarker features upper and lower flails, direct drive lower in-feed and out-feed rolls, and a floating direct drive upper feed roll. The high capacity bark pusher has been redesigned and is now 5 feet (1.5 m) wide.
Category:
Debarkers
Brand:
General Specifications
Standard Equipment
dimensions
- Operating Length: 23' 4¼"
- Operating Width: 9' 10"
- Operating Height: 9' 6"
- Operating Height (gooseneck folded up): 11' 7"
- Travel Length: 30' 5"
- Travel Width: 9' 10"
- Travel Height: 9'
- Front Ground Clearance: 10 5⁄8"
- Rear Ground Clearance: 10¾"
- Ground Clearance: 10"
- Axle Spacing: 49½"
- Front to 5th Wheel: 74¾"
- 5th Wheel to Center Axle: 23' 3½"
- 5th Wheel Height: 49½"
weights
- Machine Weight: 42,660 lbs
- 5th Wheel Weight: 11,080 lbs
- Tridem Axle Weight: 31,580 lbs
powertrain & system controls
- Engine: CAT C9.3 Tier III or Tier IV 350 hp, CAT C9.3 Tier III 350 hp export only
- Fuel Tank Capacity: 175 gal
- Hydraulic Tank Capacity: 135 gal
- Adaptive Control System: Yes
- Radio Remote: Yes
- Peterson+ Analytics: Yes
- Wireless Link with Peterson Chipper (optional): Yes
feed system
- Feed Opening (w x h): 52½" x 23"
- Feed Height: 55"
- Outfeed Height: 62"
- Feed Speed Range: up to 155 ft/min
- Maximum Log Diameter: 23"
- Upper Feed Roll: Floating Direct Drive
- Lower Feed Roll: Direct Drive Fixed
delimber/debarker
- Flails: Upper & Lower Flail Drums, Hydraulic Upper Flail Float
- Flail Drum Diameter: 10½"
- Flails Rods/Drum: 6
- Flail Chain/Drum: 5⁄8" x 8 links x 78 chains
- Drive Type: Hydrostatic
- Flail Speed Range: 400 - 600 rpm
- End Discharge Bark Mover: 60" x 19¾"
