MH3022 Wheel Material Handler

At a glance data:

Engine Model:

Cat C4.4

Net Power - ISO 9249:

145hp

Net Power - ISO 9249 (DIN):

147hp (metric)

Engine Power - Maximum - ISO 14396:

148hp

Print MH3022 (07E) Material Handler - Product Brochure (Aus-NZ, Europe, Japan, N Am, Türkiye) MH3000 Series Material Handlers - Family Brochure (N Am) Technical Specs

Overview

The Cat® MH3022 is a purpose-built material handler designed to deliver strong performance for your toughest waste and scrapyard applications. The MH3022 features simple-to-use technologies, a comfortable cab, and multiple boom and stick options to match your work. These features help create a safe, reliable product to take on the wide variety of challenges you face each day.

Category:

Wheel Material Handlers

Brand:

Cat

Engine

Engine Model:

Cat C4.4

Net Power - ISO 9249:

145hp

Net Power - ISO 9249 (DIN):

147hp (metric)

Engine Power - Maximum - ISO 14396:

148hp

Engine Power - ISO 14396 (DIN):

150hp (metric)

Bore:

4.1in

Stroke:

5in

Displacement:

268.5in³

Biodiesel Capability:

Up to B20¹

Emissions:

Meets U.S. EPA Tier 4 Final and EU Stage V emission standards.

Note (1):

Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, Clean Emission Module (CEM) exhaust gas aftertreatment, alternator, and cooling fan running at intermediate speed. Rated speed 2,000 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.

Note (2):

¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. *Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer). **Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels.

Transmission

Maximum Travel Speed:

12.4mile/h

Drawbar Pull:

28551lb/ft

Maximum Gradeability:

65%

Hydraulic System

Maximum Pressure - Implements:

5076psi

Maximum Pressure - Swing:

5294psi

Maximum Pressure - Travel:

5076psi

Swing Mechanism

Swing Speed:

8r/min

Maximum Swing Torque:

39553lbf·ft

Weights

Operating Weight:

54000lb

Note:

Operating weight includes full fuel tank, operator, 1400 kg (3,100 lb) work tool. Weight varies depending on configuration.

Service Refill Capacities

Fuel Tank Capacity:

92.5gal (US)

Cooling System:

9.5gal (US)

Engine Oil:

3.4gal (US)

Rear Axle - Housing (Differential):

3.7gal (US)

Final Drive - Each:

0.7gal (US)

Powershift Transmission:

0.7gal (US)

Hydraulic System - Including Tank:

91.1gal (US)

Hydraulic Tank:

40.9gal (US)

Diesel Exhaust Fluid (DEF) Tank:

7.9gal (US)

Dimensions

Boom:

MH 5.35 m (17'7")

Stick:

4.3 m (14'1") Straight

Shipping Length:

27.2ft

Machine Length:

16.2ft

Tail Swing Radius:

8.5ft

Counterweight Clearance:

4.3ft

Cab Height- Lowered:

11ft

Cab Height-Lowered with OPG:

11ft

Cab Height-Raised:

18.9ft

Cab Height-Raised with OPG:

18.9ft

Wheel Base:

8.5ft

Shipping Width:

8.3ft

Ground Clearance:

1ft

Undercarriage Length:

16.1ft

Working Ranges

Maximum Reach:

30.4ft

Boom:

MH 5.35 m (17'7")

Stick:

4.3 m (14'1") Straight

Maximum Height:

35.3ft

Minimum Dump Height:

10.9ft

Maximum Depth:

4.8ft

Boom Pin Height:

23.4ft

Air Conditioning System

Note (1):

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.05 kg (2.31 lb) of refrigerant which has a CO2 equivalent of 1.502 metric tonnes (1.655 tons).

Standard Equipment

note

Standard and optional equipment may vary. Consult your Cat dealer for details.

cab

Advanced sound suppressed Tip Over Protective Structure (TOPS) certified cab
High-resolution 254 mm (10") LCD touch screen monitor
Automatic bi-level air conditioner
Jog dial and shortcut keys for monitor control
Keyless push-to-start engine control
Heated seat with air suspension (Deluxe cab)
Heated and cooled seat with automatic adjustable suspension (Premium cab)

cat technology

VisionLink®
Remote Flash and Remote Troubleshoot
Cat Payload

electrical system

Maintenance-free batteries
LED chassis light, left-hand/right-hand boom and stick lights, cab lights
Centralized electrical disconnect switch
Programmable time delay LED working lights

service and maintenance

Scheduled Oil Sampling (S·O·S℠) ports
Automatic lubrication system for implement and swing system
Integrated vehicle health management system

engine

Cat C4.4 diesel engine
Three selectable modes: Power, Smart, Eco
Up to 3000 m (9,840 ft) altitude capability without engine power de-rate
Cold start capability -18°C (0°F)
52°C (125°F) high-ambient cooling capacity
On-demand electric cooling fans with auto-reverse function

hydraulic system

Boom and stick lowering control check valves
Electronic main control valve
Automatic hydraulic oil warm up
Heavy lift mode

safety and security

Rear and right-side-view cameras
Signal/warning horn
Neutral lever (lock out) for all controls
Ground-level accessible secondary engine shutoff switch in cab
2D E-fence (Available with MH booms only)
Cab Avoidance (Available with MH booms only)
Swing Assist

undercarriage and structures

All wheel drive
Automatic brake/axle lock
Creeper speed
Electronic swing and travel lock
Heavy-duty axles, advanced disc brake system, and travel motor with adjustable braking force
Lockable, oscillating front axle with remote greasing point
Two speed hydrostatic transmission
Counterweight 3700 kg (8,160 lb)
Wide undercarriage 2.55 m (8'4")
