At a glance data:
Engine Model:
CUMMINS B4.5 Stage V
Peak Power at 2,500 rpm (SAE J1995):
173 hp (129 kW)
Cylinders & Displacement:
4 cylinders/275 CID (4.5 L)
Overview
Most robust and proven dedicated mulching tractor under 200 HP; Highest torque in its class; Comes with mulching head or chipper head.
Category:
Mulching Equipment
Category:
Mulching Equipment
Brand:
Brand:
General Specifications
Engine Model:
CUMMINS B4.5 Stage V
Peak Power at 2,500 rpm (SAE J1995):
173 hp (129 kW)
Cylinders & Displacement:
4 cylinders/275 CID (4.5 L)
Standard Equipment
engine
- Manufacturer & Model: CUMMINS B4.5 Stage V
- Cylinders & Displacement: 4 cylinders/275 CID (4.5 L)
- Peak Power at 2,500 rpm (SAE J1995): 173 hp (129 kW)
- Net Peak Torque: 576 ft-lbf (780 Nm)
- Fan: Automatic variable pitch, reversible
hydraulics
- Pump System: 4
- Filtration: 10 Microns
electrical
- Voltage: 12 Volts
- Standard Light: 8 LED type (4 Front, 2 Side, 2 Rear)
serviceability
- Fuel Tank: 78.5 gal US (297 L)
- Hydraulic Reservoir (80% full): 29 gal US (110 L)
- Cooling System: 7.13 gal US (27 L)
undercarriage & ground pressure
- Chain Type & Size: Seal and lube track (SALT) D3
- Track Shoe & Rollers: Standard 22 in (560mm), Option 30 in (760mm), Single grouser with mud hole, Dozer type roller
- Ground Pressure - 22 in pads (Crawler only): 3.83 psi (0.27 kg/cm²)
- Weight - 22 in pads (Crawler only): 17,411 lb (7,900 kg)
- Ground Pressure - 30 in pads (Crawler only) 2.91 psi (0.20 kg/cm²)
- Weight - 30 in pads (Crawler only) - 18,003 lb (8,166 kg)
top speed
- Motor: Two speed hydraulic motors
- Speed: Variable speed from 0 to 3.85 mph (0 to 6.2 km/h)
standard characteristics
- Push button cab lift with manual override
- Backup camera
- AM/FM/Bluetooth radio
- Hydraulic oil filler pump
- Air suspension seat
- ROPS/FOPS/OPS Certification
Optional Equipment
