At a glance data:
Engine Model::
Cummins x15 Tier 4 stage 5
Max Power (SAE J1995)::
500 hp (372 kW) @ 1800 RPM
Cylinders & Displacement::
6 cylinders / 912 po CID (14.9 L)
Overview
Our complete selection of tractor-mulchers ranging from 125 to 600 horsepower will meet your forestry mulching needs.
Category:
Mulching Equipment
Category:
Mulching Equipment
Brand:
Brand:
General Specifications
Engine Model::
Cummins x15 Tier 4 stage 5
Max Power (SAE J1995)::
500 hp (372 kW) @ 1800 RPM
Cylinders & Displacement::
6 cylinders / 912 po CID (14.9 L)
Standard Equipment
engine
- Manufacturer & Model: CUMMINS x15 Tier 4 Stage V
- Cylinders & Displacement: 6 cylinders/912 po CID (14.9 L)
- Max Power (SAE 1995): 500 hp (372 kW) @ 1800 RPM
- Net Peak Torque: 1,700 ft-lbf (2,305 Nm)
- Fan: Automatic variable pitch, reversible
hydraulics
- Pump System: 4
- Filtration: 10 Microns
electrical
- Voltage: 12 Volts
- Standard Light: 8 LED type (4 Front, 2 Side, 2 Rear)
serviceability
- Fuel Tank: 215 gal US (814 L)
- Hydraulic Reservoir: 102 gal US (385 L)
- Cooling System: 18 gal US (68 L)
undercarriage & ground pressure
- Chain Type & Size: Seal and Lube, D-6N with an elevated final drive design
- Track Shoe & Rollers: 30 in (762 mm) single grouser with mud hole, dozer type rollers. 34 in (864 mm) pads optional
- Ground Pressure (Crawler only, 30 in pads): 5.8 psi (0.41 KG/cm2)
- Weight (Crawler only, 30 in pads): 46,925 lb (21,285 kg)
top speed
- Motor: Two speed hydraulic motors
- Speed: Variable speed from 0 to 5.2 mph (0 to 8.4 km/h)
standard characteristics
- Push button cab lift with manual override
- Backup camera
- AM/FM/Bluetooth radio
- Hydraulic oil filler pump
- Air suspension seat
- ROPS/FOPS/OPS Certification
- 12 Volts DC outlet
Optional Equipment
